- Adjustable brightness. On time 2 minutes.
- Ideal for stair landings, doorways and corridors.
- The twilight movement detector designed to automate lighting.
- Detects movement and lack or excess of light to switch the bulb on or off.
- LED compatible.
Motion Detector Ceiling Surface 360º Compatible LED
MF1024
More info about this product
- Suitable for stair landings, doorways and corridors.
- For use with LED bulbs.
- Detection distance 6m. Detection time adjustable from 10s to 7min.
- 360 degree angle.
- Automatic motion switch.
See more
(editar con el módulo de Información de seguridad y confianza para el cliente)
(editar con el módulo de Información de seguridad y confianza para el cliente)
(editar con el módulo de Información de seguridad y confianza para el cliente)
Guarantee safe & secure checkout
The presence detector with motion sensor is an automatic motion switch. The detector is activated when it detects movement within its reception field and is deactivated after an adjustable delay of between 10 seconds and 7 minutes, when it stops detecting movement.
It has a detector with adjustable light sensitivity between 10-2000 lux, the operation of the sensor can be adjusted for each type of ambient lighting. If we adjust the LUX function towards the sun or day mode, it will work according to the lux setting chosen both day and night, on the other hand if we adjust it in the LUX function towards the moon or night mode, it will only work at night.
It is used for surface mounting on the ceiling with a detection area of 360º and has a maximum detection distance of 6 metres. The nominal voltage at which the detector operates is 230V/50Hz.
It has an IP20 protection rating, is suitable for indoor use with a maximum admissible power of 1200W.
The dimensions of the product are 85 millimetres in diameter and 40 millimetres deep.
The connection of this detector is recommended for LED lighting and always making the connection by means of the three wires (phase, neutral and return of the bulb).
The detector is an ideal element for areas where you want to automate the lighting and switch on electronic devices when they detect movement, such as staircases, basements, doorways, offices, libraries, school classrooms, bathrooms, etc.
Benefit from the best prices and offers on the market in our Atomant LED lighting online shop.
Data sheet
- Measurements
- Ø85x40mm
- Protection
- IP20
- Material
- PC
- Installation
- Surface
- Aperture
- 360º
- Information
- Maximum detection distance 6m
Specific References
- ean13
- 8436586847388
Muy muy facil de instalar porque viene con todo lo necesario (tacos y tornillos incluidos)
